pit type quench vacuum carburising furnace

Vacuum gas quenching hardening Furnace for extrusion die Vacuum air-cooled furnace Horizontal real air quenching furnace

APPLICATION:

Quench

Hardneing

tempering

annealing

carburization

Stress relief

And so on

 Can have both LPC (low pressure carburizing) and LPCN (low pressure carbonitriding) functions
⚫ LPC and LPCN production process simulation system, process database and process control system
⚫ Intelligent flow calculation, more accurate carbon potential control, and maximum reduction of carbon black and tar
⚫ Fully intelligent industrial computer process control system, reducing complex operations for personnel, simple operation, flexible input of process editing, and machine
Mechanical action is stable and reliable
⚫ Production history record query, alarm and equipment failure history record query
⚫ Quenching gas: nitrogen/argon/helium
⚫ Quenching pressure: 6-20bar optional
⚫ Gas flow rate is controlled by frequency converter
⚫ Small deformation of workpiece, high production efficiency and low experimental cost
⚫ Alternating air flow, the air flow direction is variable, which can achieve top-down cooling or bottom-up cooling, and the air flow direction can be quickly realized
For changes, you can also choose sealed heating and 360-degree annular cooling. This structure can be vacuum carburized and the mold can be quenched to reduce the cost.
Heat loss can effectively save energy by 15-20%. On this basis, 360-degree annular cooling + upper and lower alternating air cooling can be upgraded to make the equipment more advantageous.
protrude

Specification
